HD 12X Optical zoom 71degree HOV, H.265/H.264/MJPEG,HDMI/
3G-SDI, AUDIO IN, RTSP、RTMP
Highlights:
n Advanced New 4K UHD PTZ Camera Design
PrivateTooling & Patent Design
n 3840X2160@30fps
1/2.8″Progressive COMS, 8.42 M pixel quality sensoroutput 4K@30fps
n HD optic lens, 12x
12x optical zoom, HOV 71 degree Wide view angle, F1.8-F2.8
n Auto Frame
Auto frame keep everyonein centre when people join or exit meeting
n PTZ Mechanism
Pan movement ±165°, Tilt Movement: ±30°
n PTZ Control protocol
PELCO-D,VISCA, PELCO-P, UVC1.5
n Network protocol
RTSP, RTMP, ONVIF
n Video output connector
3G-SDI,HDMI, USB3.0
Image sensor Parameters | |
Sensor | 1/2.8″Progressive COMS，8.42 megapixel |
Zoom | 12X |
Focus | f=4.14-47.08mm |
Iris | F1.8-F2.8 |
HOV | 6.57°-70.28° |
Min illumination | 0.5Lux at F1.6 |
Exposure | Auto, shutter priority |
Shutter | 1/25～1/10,000 S |
Auto, Shutter priority | |
Line in | 3.5mm Audio input socket |
S/N Ratio | ≥50dB |
ON/OFF | |
Gain control | Auto |
Image Flip | Image reverse, Mirror flip |
OSD Menu | LENS OSD, DOME OSD |
OSD Menu | Chinese, English |
PTZ Parameters | |
Horizontal Movement | -175°～ +175° |
Tilt Movement | -30°～ +90° |
· Horizontal movement speed | 0.1°～ 100°/S |
· Tilt movement speed | 0.1°～ 72°/S |
Speed Match | Support |
Command Protocol | VISCA, PELCO-D |
Preset Position | 255 (including special preset position) |
38400bps,9600bps,4800bps,2400bps | |
Network protocol | RTSP, RTMP, ONVIF |
Input/output Connectors | |
DC IN | DC IN 12V |
3G-SDI,DVI-I, USB2.0, LAN(DVI-I to HDMI, YPbPr) | |
Video output | 1080p60/50, 1080i60/50, 720p60/50/30/25 |
Communication control interface | RS-232C, RS-485 |
General info | |
Power supply | DC12V±10%,2A |
Working Environment | Working temperature 0～50, working humidity 10%～95% |
Dimension(LxWxH)
| 250mm×140mm×154mm |
Weight | 1400g |
Color | |
